SDR-960-48
SKU : SDR-960-48
| Price |
275.00 USD 295.00 USD (-7%) |
| Quantity to buy | |
| Total | 275.00 USD |
Do not have enough stock
Out of stock
960W Single Output Industrial DIN RAIL with PFC Function SDR-960 Series
Features :
- AC input 180-264VAC only
- 130% peak load capability
- 110mm slim design
- Built-in active PFC function compliance to EN61000-3-2
- High efficiency 94% and low power dissipation
- Protections: Short circuit / Overload/Over voltage / Over temperature
- Cooling by free air convection
- Built-in constant current limiting circuit
- Can be installed on DIN rail TS-35/7.5 or 15
- UL508 (industrial control equipment) approved
- EN61000-6-2(EN50082-2) industrial immunity level
- Current sharing up to 3840W(3+1)
- Built-in DC OK relay contact
- 100% full load burn-in test
- 3 years warranty
