ICL-16R

SKU : ICL-16R

16A AC Inrush Current Limiter ICL-16R/16L Series

Description :

The ICL-16 is a 16A inrush current limiter that can be used to reduce the high starting current due to capacitive load causing the circuit breaker to be false triggered. Several power supplies can be installed on the same AC line after the implementation of an ICL-16.

Features :

1. 23A inrush limiting current, 16A continuous
2. 180~264VAC AC input
3. Integrated bypass relay, no simple NTC
4. Internal thermal protection
5. Installed on DIN Rail TS-35/7.5 or 15 (ICL-16R)
6. 1-30-+70°C wide working temperature
7. 3 years warranty

Applications :

1. Allow connecting multiple power supply
2. at same line
3. Allows smaller and faster Circuit Breaker
4. Capacitive load
5. Protects against unintended trigger of
6. Circuit Breaker
