HBG-240P-48B

SKU : HBG-240P-48B

240W Constant Voltage + Constant Current LED Driver HBG-240P series

*Type B Function l 3 in 1 dimming function (1-10Vdc, 10V PWM signal and resistance) Note In Stock

Description :

HBG-240P series is a 240W AC/DC PCB type LED driver featuring the circular shape design. It operates from 90-305VAC and offers the dual mode constant voltage and constant current output models with different rated voltage ranging between 36V and 60V. Thanks to the high efficiency up to 93.5%, with the fanless design, the entire series is able to operate for -40°C - +45°C under free air convection. HBG-240P is equipped with various function options, such as dimming methodology, so as to provide the optimal design flexibility for LED lighting system.

Features :

1. Constant Voltage + Constant Current mode output
2. Circular shape PCB type design
3. Built-in active PFC function
4. Function options: output adjustable via potentiometer;
5. 3 in 1 dimming
6. Typical lifetime>50000 hours
7. 5 years warranty

Applications :

1. LED bay lighting
2. LED down lighting
3. LED spot lighting
4. LED mining lighting
5. LED stage lighting
