PWM-60(DA)-36-Blank

SKU : PWM-60(DA)-36-Blank

60W PWM Output LED Driver PWM-60 series

*Type Blank IP67 3 in 1 dimming function (0-10Vdc, 10V PWM signal and resistance) Note : In Stock  Power Output :60.12W. / Voltage : 36V / Current : 1.67A.

Description

PWM-60 series is a 60W LED AC/DC LED driver featuring the constant voltage mode with PWM style output, which is able to maintain the brightness homogeneity when driving all kinds of LED strips. PWM-60 operates from 90-305VAC and offers models with different rated voltage ranging between 12V and 48V. Thanks to the high efficiengy up to 90%, with the fanless design, the entire series is able to operate for -40°C ~ +85°C case temperature under free air convection. The entire series is rated with IP67 ingress protection level and is suitable to work for dry, damp or wet locations. PWM-60 is equipped with dimming function that varies the duty cycle of the output, providing great flexibility for LED strips applications.

Features

• Constant Voltage PWM style output
• Emergency lighting application is available
• according to IEC61347-2-13
• Built-in active PFC function and class 11/2 design
• No load power consumption <0.5W
• Fully encapsulated with IP67 level
• Function: 3 in 1 dimming(dim-to-off); DALI/DALI 2.0
• Minimum dimming level 0.2% for DALI type
• Typical lifetime>50000 hours and 5 years warranty

Applications

• LED strip lighting
• Indoor LED lighting
• LED decorative lighting
• LED architecture lighting
• Type "HL" for use in Class I, Division 2
• hazardous (Classified) location.
