M_IS05.1 KNX Mini PIR & Lux Sensor

 Feature

• With 2CH lighting control, 4 sections of brightness and delay time can be set in dimming output. With gradually dimming effect, the sensor supports automatic or semiautomatic mode. Telegram locking/unlocking and delay time can be set. Sending on/off telegram can be set when locking and unlocking.
• With 2CH constant brightness control, dimming values and forced operation can be set.
• The sensor has 5 logic blocks and each block contains 10 object outputs. Telegram locking/unlocking and delay time can be set. Sending on/off telegram can be set when locking and unlocking.
• Control types: Switch control, Absolute dimming control, Shutter control, Alarm control, Percentage control , Sequence control, Scene control, String(14 bytes) control, Threshold control, Logic combination control.
• Logic inputs: PIR sensing status, brightness value, temperature and external telegrams.
• 2 logical relations: AND, OR
• 2 working modes: Single mode and master / slave mode.
• The logic validity can be set by external telegram.

Basic Parameters

 External Environment

Specifications

• Working voltage 21~30V DC
• Working current 5mA/30V DC
• Communication KNX
• Cable diameter of KNX terminal 0.6 - 0.8mm
• PIR detection range Φ8m (Installation height:3m)

• Working temperature -5℃~45℃
• Working relative humidity ≤90%
• Storage temperature -20℃~60℃
• Storage relative humidity ≤93%

• Dimensions Φ63×46.6 (mm)
• Net weight 43g
• Housing material ABS,PC,iron
• Installation Ceiling-mounted/Flush-mounted
• Protection rating (Compliant with EN 60529) IP20
